| Important Enhancements & Fixes

Common Framework Across Tools

The common framework provides the users with a consistent builder, sharing mechanism, like, bookmark, adding description, and custom arrangement capability across Summary table, Heatmap Filters, Custom Parameters, Analytics, and Site Sequencer.




Common Framework - Summary Table:
Common Framework for summary table provides users with a consistent builder, sharing mechanism, like, bookmark adding description for tables and other enhancements.

GetImage (1).png

Biometric Login for Apps

Biometric login is introduced for Facilisight and Occupant app to make the applications more user friendly and secure. The implementation of biometric logins helps the user to avoid frequent logouts and further enables easy access to 75F applications.


Damper Position & Zone Priority Driven Trim and Respond Requests

All our terminal profile-related algorithms follow the Guideline 36 norms in every sequence of its operation. For the Trim and response sequences, we have implemented the corresponding influencing parameters as tuners, and they play a vital role in energy savings.


Central Plant with Plate Heat Exchanger (PHE)

The Plate Heat Exchanger is equipment in the chiller circuit, that favors the transfer of energy from the cooling to the heating side and vice versa.

mceclip0 (1).png

Wired Helionode

Wired HelioNode is a new introduction within the 75F systems. This aspect lets the users wire a HelioNode to a CCU to aggregate data from the HelioNode to the cloud and consume the control sequences from the CCU for its operation.


Wired Smartnode

Wired SmartNode is a new introduction within the 75F systems. This aspect lets the users wire a SmartNode to a CCU to aggregate data from the SmartNode to the cloud and consume the control sequences from the CCU for its operation.


| New & Updated Docs

Biometric Login for Apps

Wired SmartNode

Setting SmartNode for Wired Communication & Control

Wired HelioNode

Setting HelioNode for Wired Communication & Control

True CFM (Cubic Feet Per Minute) VAV

Existing Sites Migration to Scheduler V2

Common Framework for Tools

Installer User Group: Certified Installer & Integrator Roles

Damper Position & Zone Priority Driven Trim and Respond Requests

Forced Recalibration of MultiSensor CO2 Sensor

Forced Recalibration of HyperStat CO2 Sensor

Summary Table - Common Framework

Central Plant with Plate Heat Exchanger (PHE)

Custom Heatmap Filter

VAV Terminal Profile- Damper Position Calculation & Operation

HyperStat Standalone Conventional Package Unit (CPU)

HyperStat Standalone HPU (Heat Pump Unit)

HyperStat Standalone 2 Pipe Fan Coil Unit (2PFCU)

HyperStat Standalone 4 Pipe Fan Coil Unit (4PFCU)

| Versions

Software Releases
Internal Portal 2.73.0
Facilisight Portal 2.69.0
CCU 2.2.8
Facilisight App 2.0.10
Occupant App 2.0.10
Firmware/ Hardware Releases
SmartNode 5.23
5.29
HelioNode 6.21
