September 2024 Release

| Important Enhancements & Fixes

Analytics- Common Framework with Blockly

The Analytics feature includes the existing custom widgets capability which have been enhanced with a common framework featuring calculated parameters with Blockly support for parameter conditions. Also, additional enhancements have been introduced which include dual Y-axis configuration, Y-axis scaling, with minimum/maximum configuration values, enabling users to derive deeper insights and make more informed decisions.

Alerts on Graphics

This feature enhances alert visibility by introducing color-coded Alert Rings to indicate the severity of alerts—Severe, Moderate, and Low, enabling quick identification of urgent issues. Additionally, active equipment alerts will be displayed in an accordion format on each System and Zone Page, allowing users to easily view all current alerts at a glance.

| New and Updated Docs

Analytics - Common Framework with Blockly

Equip Graphics for System Profile

VAV w/ Reheat (Parallel Fan)

VAV w/ Reheat (No Fan)

VAV w/ Reheat (Series Fan)

DAB Terminal Profile

SmartNode- Active Chilled Beam+ Dedicated Outside Air System (DOAS)

HyperStat Split- CPU & Economizer Profile

HyperStat Heat Pump Unit (HPU)

HyperStat 2 Pipe Fan Coil Unit (2PFCU)

Airflow CFM & Reheat Loops on SmartNode & HelioNode

External API Requests From Site Sequencer

CCU VAV Advanced Hybrid AHU v2- Sequence of Operation

CCU Outside Air Optimizer (OAO) System Profile - Sequence of Operation

SmartNode / HelioNode Active Chilled Beams - Sequence of Operations

VAV Advanced Hybrid AHU v2 with Advanced AHU Controls

| Software Release Versions

| Firmware/Hardware Feature Availability Versions
