August 2024 Release

Important Enhancements & Fixes

CCU Remote Access

With the CCU Remote Access feature, users can remotely manage CCUs and view system/zone reconfigurations directly through the portal. This enhancement provides reliable access with reduced failure points, allowing for real-time diagnostics and remote troubleshooting. Users could start and stop remote sessions seamlessly, with clear status indicators and audit trails to track user activity and session details.

QR Code & Short URL for Facilisight & Internal Portal

This feature enables end users to easily access the System or Zone-associated data by scanning a QR code from a mobile phone or tablet, creating a short URL for it or further printing it. The scan page will include the equipment graphics data and predefined widgets that will empower users to visualize insights and understand broader aspects of working the equipment that will help them troubleshoot or service equipment at the site.

CPM Enhancements

The usability of overlapping pipelines in the plant, which create unclear water flow directions in pipes, is handled. This also addresses enhancements to identify incomplete plants being built upon publishing, enhances the size of the status rings, and hides the non-available click-view parameters.

Notes File Upload

This feature will allow users to add files and associate with System or Zone Equipment on their Sites. This will enable users to store site-specific documents on the portal itself and when required can be accessible remotely for reference.

Fan Pressure Control on Selection in Advanced AHU

The naming convention of the Fan Pressure Control selection under Analog In and sensor bus address setting configuration in the Advanced AHU profile is streamlined for better usage and sensor input validation support.

Sensor Input Validation in Advanced AHU

The Advanced AHU profile now comes with validations for the right kind and way of sensor input selection.

N/O and N/C Based Water Valve Operation for ACB+DOAS Profiles

The Helionode and Smartnode Active Chilled Beams+ DOAS profiles can now support options, N/O & N/C Generic Fault Detection from the thermistor inputs. The SmartNode and Helionode use the calculated PI loop Output during the failsafe to decide the command for the relay port-based valve operation

| New and Updated Docs

Heatmap Notes

Central Plant Builder Nuances, Validations and Restrictions

QR Code & Short URL for Facilisight & Internal Portal

HyperStat Split- CPU & Economizer Profile

VAV Advanced Hybrid AHU v2 with Advanced AHU Controls

SmartNode- Active Chilled Beam+ Dedicated Outside Air System (DOAS)

HelioNode- Active Chilled Beam+ Dedicated Outside Air System (DOAS)
