| Important Enhancements & Fixes
Temperature Mode
Temperature Modes introduces configurable temperature interaction modes across the CCU, portals, occupant applications, and supported devices. These modes define how heating and cooling desired temperatures are presented to users and how they respond to user adjustments.
The objective is to:
Improve user comfort control experience
Reduce user confusion in managing dual setpoints
Maintain system stability and configure deadbands
Provide flexible UI representations depending on device or application context
It introduces building-level temperature control modes and zone/device-level temperature interaction modes.
Temperature Modes, Dual Setpoint Fixed Deadband & Variable Deadband- Facilisight Web App
Temperature Modes, Single Setpoint & Setpoint Offset Modes- Facilisight Web App
Temperature Modes, Dual Setpoint Fixed Deadband & Variable Deadband- Facilisight Mobile App
Temperature Modes, Single Setpoint & Setpoint Offset Modes- Facilisight Mobile App
Temperature Mode Simulator
The Temperature Mode Simulator provides an interactive environment for validating temperature control configurations before they are applied to a zone schedule. Instead of making configuration changes directly on a schedule and observing the behavior later, users can simulate how different temperature modes respond using the current user limits, desired temperatures, deadbands, offsets, and conditioning modes.
The simulator enables facility managers and commissioning engineers to compare multiple temperature control strategies side-by-side and understand how each mode affects zone operation. Once the desired configuration has been validated, the simulated settings can be applied directly to the selected schedule.
Purpose
The Temperature Mode Simulator helps users:
- Visualize the behavior of various temperature control modes.
- Validate heating and cooling setpoints before deployment.
- Compare different operating strategies without affecting live schedules.
- Verify user limits and deadband configurations.
- Reduce configuration errors during schedule creation.
- Apply validated settings directly to zone schedules.
API Management in Facilisight as an add-on subscription
The API Management page provides administrators and authorized support users with secure access to the API subscription keys required for integrating external applications with the 75F platform. It serves as a centralized location for viewing, copying, and managing authentication keys for the available APIs.
The feature simplifies API consumption by exposing separate subscription keys for different API categories while maintaining secure access control through user permissions.
Note: The API Management feature is available to customers as a subscription-based add-on. For information on subscribing to the feature and understanding the associated billing model, refer to the API Management Subscription and Billing section in Subscription Management.
Easy Street Scheduling & Metrics and Enhancements
Easy Street is an automated commissioning tool that validates the functionality and logic of profiles connected to a 75F CCU. By replacing manual testing with a standardized backend validation script, Easy Street helps ensure consistent results, reduces commissioning time, and provides a comprehensive assessment of system health.
Users can initiate an installation test from the Easy Street page for a selected CCU. The test automatically evaluates profile points and control logic, then generates a site installation score that reflects the accuracy and completeness of the configuration.
Facility managers and other authorized users can review these scores and test results to verify installation quality and identify potential issues.
Easy Street - Facilisight Portal
Easy Street - Internal Portal
Easy Street - Facilisight App
| New & Updated Docs
Creating, Applying and Editing Special Events
Temperature Modes, Dual Setpoint Fixed Deadband & Variable Deadband- Facilisight Web App
Temperature Modes, Single Setpoint & Setpoint Offset Modes- Facilisight Mobile App
Temperature Modes, Single Setpoint & Setpoint Offset Modes- Facilisight Web App
Creating and Editing Special Schedules (App Version)
Connect Module Overview & Installation
HyperStat Interactivity Lockout
CCU Session Reactivation After 60 Days
Site Installation Report Via Easy Street - Facilisight App
Site Installation Report Via Easy Street - Internal Portal
Site Installation Report Via Easy Street - Facilisight Portal
SmartNode VAV with Reheat (No Fan) Profile
SmartNode VAV w/ Reheat (Series Fan) Profile
SmartNode VAV w/ Reheat (Parallel Fan) Profile
Smart Node V2 Wiring Reference
Temperature Mode: Single Setpoint (CCU)
Temperature Mode: Dual Setpoint Fixed Deadband (CCU)
Temperature Mode: Dual Setpoint Variable Deadband (CCU)
Temperature Modes: Overview (CCU)
| Software Release Versions
| Component | Latest Version |
| CCU | 5.5.3 and above |
| Home App | 5.1.1 and above |
| Remote Access App | 5.1.0 and above |
| BACnet App | 5.3.2 and above |
| Internal Portal | 5.196.0 and above |
| Facilisight | 5.165.0 and above |
| Facilisight App | 5.2.7 and above |
| Occupant App | 5.1.1 and above |
| Firmware/ Hardware Feature Availability Versions
| Firmware/ Hardware | Feature Availability Versions |
| HyperLite | 106.0.0 and above |
| Mystat | 2.13.0 and above |
| Mysense | 1.6.0 and above |
| Control Mote | 6.1.0 and above |
| SmartNode | 6.2.0 and above |
| Smartnode V2 | 102.11.0 and above |
| HyperStat Main Board | 2.1.0 and above |
| Connect Module | 6.0 and above |
